Implementation of PCB Layout using CNC Machine Controlling with Wireless Communication

Abstract

CNC machine are an important part in mass production field. These machines are fast, more precious and compatible. The objective of this project is developed economically three-dimensional CNC machine for PCB laying which can be monitor through Bluetooth (hc-05). The primary province of this CNC machine is to draw the PCB layout and to connect the personal computer with control machine. There has been an increased demand in market for accurate and province CNC machine for PCB layout controlled through Bluetooth. So our mission is to design low cost computerized numerical control for PCB drawing controlled through HC-05. The main aim of this project is to design cost effective systems. The proposal of system based on Arduino microcontroller and also it maintains precision and reliable required for problematic shapes with ninety-eight percent (98%) accuracy.
